Embedded Flash memory (FLASH) RM0444
72/1390 RM0444 Rev 5
Note: For a virgin data: 0xFF FFFF FFFF FFFF FFFF, one error is detected and corrected, but two
errors detection is not supported.
When an ECC error is reported, a new read at the failing address may not generate an ECC
error if the data is still present in the current buffer, even if ECCC and ECCD are cleared. If
this is not the desired behavior, the user must reset the cache.
3.3.4 FLASH read access latency
To correctly read data from Flash memory, the number of wait states (LATENCY) must be
correctly programmed in the FLASH access control register (FLASH_ACR) according to the
frequency of the Flash (HCLK) memory clock and the internal voltage range of the device
V
CORE
. Refer to Section 4.1.4: Dynamic voltage scaling management. Table 12 shows the
correspondence between wait states and Flash memory clock frequency.
After power reset, the HCLK clock frequency is 16 MHz in Range 1 and 0 wait state (WS) is
configured in the FLASH_ACR register.
When wakeup from Standby, the HCLK clock frequency is 16 MHz in Range 1 and 0 wait
state (WS) is configured in the FLASH_ACR register.
When changing the Flash memory clock frequency or Range, the following software
sequences must be applied in order to tune the number of wait states needed to access the
Flash memory:
Increasing the CPU frequency
1. Program the new number of wait states to the LATENCY bits of the FLASH access
control register (FLASH_ACR).
2. Check that the new number of wait states is taken into account to access the Flash
memory by reading back the LATENCY bits of the FLASH access control register
(FLASH_ACR), and wait until the programmed new number is read.
3. Modify the system cock source by writing the SW bits of the RCC_CFGR register.
4. If needed, modify the core clock prescaler by writing the HPRE bits of RCC_CFGR
register.
5. Optionally, check that the new system clock source or/and the new core clock prescaler
value is/are taken into account by reading the clock source status (SWS bits) of the
RCC_CFGR register, or/and the AHB prescaler value (HPREF bit), of the RCC_CFGR
register.
Table 12. Number of wait states according to Flash memory clock (HCLK) frequency
Wait states (WS)
(LATENCY)
HCLK (MHz)
V
CORE
Range 1 V
CORE
Range 2
0 WS (1 HCLK cycles) ≤ 24 ≤ 8
1 WS (2 HCLK cycles) ≤ 48 ≤ 16
2 WS (3 HCLK cycles) ≤ 64 -
