RM0444 Rev 5 625/1390
RM0444 General-purpose timers (TIM2/TIM3/TIM4)
701
22 General-purpose timers (TIM2/TIM3/TIM4)
22.1 TIM2/TIM3/TIM4 introduction
The general-purpose timers consist of a 16-bit/32-bit auto-reload counter driven by a
programmable prescaler.
They may be used for a variety of purposes, including measuring the pulse lengths of input
signals (input capture) or generating output waveforms (output compare and PWM).
Pulse lengths and waveform periods can be modulated from a few microseconds to several
milliseconds using the timer prescaler and the RCC clock controller prescalers.
The timers are completely independent, and do not share any resources. They can be
synchronized together as described in Section 22.3.19: Timer synchronization.
22.2 TIM2/TIM3/TIM4 main features
General-purpose TIMx timer features include:
• 16-bit (TIM3, TIM4
(a)
) or 32-bit (TIM2) up, down, up/down auto-reload counter.
• 16-bit programmable prescaler used to divide (also “on the fly”) the counter clock
frequency by any factor between 1 and 65535.
• Up to 4 independent channels for:
– Input capture
– Output compare
– PWM generation (Edge- and Center-aligned modes)
– One-pulse mode output
• Synchronization circuit to control the timer with external signals and to interconnect
several timers.
• Interrupt/DMA generation on the following events:
– Update: counter overflow/underflow, counter initialization (by software or
internal/external trigger)
– Trigger event (counter start, stop, initialization or count by internal/external trigger)
– Input capture
– Output compare
• Supports incremental (quadrature) encoder and hall-sensor circuitry for positioning
purposes
• Trigger input for external clock or cycle-by-cycle current management
a. TIM4 is available on the STM32G0B1xx and STM32G0C1xx devices only.
