RM0444 Rev 5 255/1390

RM0444 System configuration controller (SYSCFG)

269

8.1.7 SYSCFG interrupt line 4 status register (SYSCFG_ITLINE4)

Address offset: 0x90

System reset value: 0x0000 0000

Bits 31:2 Reserved, must be kept at reset value.

Bit 1 FLASH_ECC: Flash interface ECC interrupt request pending

Bit 0 FLASH_ITF: Flash interface interrupt request pending

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

CRS

(1)

RCC

1. Only significant on devices integrating the corresponding peripheral, otherwise reserved. Refer to Section 1.4: Availability

of peripherals.

Bits 31:2 Reserved, must be kept at reset value.

Bit 1 CRS: CRS interrupt request pending

Bit 0 RCC: Reset and clock control interrupt request pending
