15.12.2 ADC interrupt enable register (ADC_IER)
Address offset: 0x04
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res.
CCRD
YIE
Res.
EOCAL
IE
Res.
AWD3I
E
AWD2I
E
AWD1I
E
Res. Res. OVRIE EOSIE EOCIE
EOSMP
IE
ADRDY
IE
rw rw rw rw rw rw rw rw rw rw
Bits 31:14 Reserved, must be kept at reset value.
Bit 13 CCRDYIE: Channel Configuration Ready Interrupt enable
This bit is set and cleared by software to enable/disable the channel configuration ready interrupt.
0: Channel configuration ready interrupt disabled
1: Channel configuration ready interrupt enabled
Note: The software is allowed to write this bit only when ADSTART bit is cleared to 0 (this ensures
that no conversion is ongoing).
Bit 12 Reserved, must be kept at reset value.
Bit 11 EOCALIE: End of calibration interrupt enable
This bit is set and cleared by software to enable/disable the end of calibration interrupt.
0: End of calibration interrupt disabled
1: End of calibration interrupt enabled
Note: The software is allowed to write this bit only when ADSTART bit is cleared to 0 (this ensures
that no conversion is ongoing).
Bit 10 Reserved, must be kept at reset value.
Bit 9 AWD3IE: Analog watchdog 3 interrupt enable
This bit is set and cleared by software to enable/disable the analog watchdog interrupt.
0: Analog watchdog interrupt disabled
1: Analog watchdog interrupt enabled
Note: The Software is allowed to write this bit only when ADSTART bit is cleared to 0 (this ensures
that no conversion is ongoing).
Bit 8 AWD2IE: Analog watchdog 2 interrupt enable
This bit is set and cleared by software to enable/disable the analog watchdog interrupt.
0: Analog watchdog interrupt disabled
1: Analog watchdog interrupt enabled
Note: The Software is allowed to write this bit only when ADSTART bit is cleared to 0 (this ensures
that no conversion is ongoing).
Bit 7 AWD1IE: Analog watchdog 1 interrupt enable
This bit is set and cleared by software to enable/disable the analog watchdog interrupt.
0: Analog watchdog interrupt disabled
1: Analog watchdog interrupt enabled
Note: The Software is allowed to write this bit only when ADSTART bit is cleared to 0 (this ensures
that no conversion is ongoing).
Bits 6:5 Reserved, must be kept at reset value.
