41 Device electronic signature
The device electronic signature is stored in the System memory area of the Flash memory
module, and can be read using the debug interface or by the CPU. It contains factory-
programmed identification and calibration data that allow the user firmware or other external
devices to automatically match to the characteristics of the STM32G0x1 microcontroller.
41.1 Unique device ID register (96 bits)
The unique device identifier is ideally suited:
• for use as serial numbers (for example USB string serial numbers or other end
applications)
• for use as part of the security keys in order to increase the security of code in Flash
memory while using and combining this unique ID with software cryptographic
primitives and protocols before programming the internal Flash memory
• to activate secure boot processes, etc.
The 96-bit unique device identifier provides a reference number which is unique for any
device and in any context. These bits cannot be altered by the user.
Base address: 0x1FFF 7590
Address offset: 0x00
Read only = 0xXXXX XXXX where X is factory-programmed
Address offset: 0x04
Read only = 0xXXXX XXXX where X is factory-programmed
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
UID[31:16]
rrrrrrrrrrrrrrrr
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
UID[15:0]
rrrrrrrrrrrrrrrr
Bits 31:0 UID[31:0]: X and Y coordinates on the wafer expressed in BCD format
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
UID[63:48]
rrrrrrrrrrrrrrrr
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
UID[47:32]
rrrrrrrrrrrrrrrr
