Note: The bits of this register are cleared 2 APB clock cycles after setting their corresponding
clear bit in the RTC_SCR register.
30.6.19 RTC masked interrupt status register (RTC_MISR)
Address offset: 0x54
Backup domain reset value: 0x0000 0000
System reset: not affected
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. ITSF TSOVF TSF WUTF ALRBF ALRAF
rrrrrr
Bits 31:6 Reserved, must be kept at reset value.
Bit 5 ITSF: Internal timestamp flag
This flag is set by hardware when a timestamp on the internal event occurs.
Bit 4 TSOVF: Timestamp overflow flag
This flag is set by hardware when a timestamp event occurs while TSF is already set.
It is recommended to check and then clear TSOVF only after clearing the TSF bit. Otherwise,
an overflow might not be noticed if a timestamp event occurs immediately before the TSF bit
is cleared.
Bit 3 TSF: Timestamp flag
This flag is set by hardware when a timestamp event occurs.
If ITSF flag is set, TSF must be cleared together with ITSF.
Bit 2 WUTF: Wakeup timer flag
This flag is set by hardware when the wakeup auto-reload counter reaches 0.
This flag must be cleared by software at least 1.5 RTCCLK periods before WUTF is set to 1
again.
Bit 1 ALRBF: Alarm B flag
This flag is set by hardware when the time/date registers (RTC_TR and RTC_DR) match the
alarm B register (RTC_ALRMBR).
Bit 0 ALRAF: Alarm A flag
This flag is set by hardware when the time/date registers (RTC_TR and RTC_DR) match the
alarm A register (RTC_ALRMAR).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
ITS
MF
TSOV
MF
TS
MF
WUT
MF
ALRB
MF
ALRA
MF
rrrrrr
