AES hardware accelerator (AES) RM0444
516/1390 RM0444 Rev 5
20.7.5 AES key register 0 (AES_KEYR0)
Address offset: 0x10
Reset value: 0x0000 0000
20.7.6 AES key register 1 (AES_KEYR1)
Address offset: 0x14
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
KEY[31:16]
wwwwwwwwwwwwwwww
1514131211109876543210
KEY[15:0]
wwwwwwwwwwwwwwww
Bits 31:0 KEY[31:0]: Cryptographic key, bits [31:0]
This write-only bitfield contains the bits [31:0] of the AES encryption or decryption key, depending on
the operating mode:
- In Mode 1 (encryption), Mode 2 (key derivation) and Mode 4 (key derivation then single
decryption): the value to write into the bitfield is the encryption key.
- In Mode 3 (decryption): the value to write into the bitfield is the encryption key to be derived before
being used for decryption.
Note: In mode 4 (key derivation then single decryption) the bitfield always contains the encryption
key.
The AES_KEYRx registers may be written only when KEYSIZE value is correct and when the AES
peripheral is disabled (EN bit of the AES_CR register cleared). Note that, if, the key is directly
loaded to AES_KEYRx registers (hence writes to key register is ignored and KEIF is set).
Refer to Section 20.4.14: AES key registers on page 507 for more details.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
KEY[63:48]
wwwwwwwwwwwwwwww
1514131211109876543210
KEY[47:32]
wwwwwwwwwwwwwwww
Bits 31:0 KEY[63:32]: Cryptographic key, bits [63:32]
Refer to the AES_KEYR0 register for description of the KEY[255:0] bitfield.
