General-purpose timers (TIM14) RM0444

722/1390 RM0444 Rev 5

Figure 229. Counter timing diagram, update event when ARPE=1 (TIMx_ARR

preloaded)

24.3.3 Clock selection

The counter clock can be provided by the following clock sources:

• Internal clock (CK_INT)

Internal clock source (CK_INT)

The internal clock source is the default clock source for TIM14.

Figure 230 shows the behavior of the control circuit and the upcounter in normal mode,

without prescaler.

MS31083V2

CK_PSC

Timerclock = CK_CNT

Counter register

Update event (UEV)

Counter overflow

Update interrupt flag

(UIF)

03 04 05

07F1

F3 F4

F5F0

CEN

Auto-reload preload

Write a new value in TIMx_ARR

Auto-reload shadow
