General-purpose timers (TIM14) RM0444
732/1390 RM0444 Rev 5
24.4.4 TIM14 event generation register (TIM14_EGR)
Address offset: 0x14
Reset value: 0x0000
Bits 15:10 Reserved, must be kept at reset value.
Bit 9 CC1OF: Capture/Compare 1 overcapture flag
This flag is set by hardware only when the corresponding channel is configured in input
capture mode. It is cleared by software by writing it to ‘0’.
0: No overcapture has been detected.
1: The counter value has been captured in TIMx_CCR1 register while CC1IF flag was
already set
Bits 8:2 Reserved, must be kept at reset value.
Bit 1 CC1IF: Capture/compare 1 interrupt flag
This flag is set by hardware. It is cleared by software (input capture or output compare mode)
or by reading the TIMx_CCR1 register (input capture mode only).
0: No compare match / No input capture occurred
1: A compare match or an input capture occurred.
If channel CC1 is configured as output: this flag is set when he content of the counter
TIMx_CNT matches the content of the TIMx_CCR1 register. When the content of
TIMx_CCR1 is greater than the content of TIMx_ARR, the CC1IF bit goes high on the
counter overflow (in up-counting and up/down-counting modes) or underflow (in down-
counting mode). There are 3 possible options for flag setting in center-aligned mode, refer to
the CMS bits in the TIMx_CR1 register for the full description.
If channel CC1 is configured as input: this bit is set when counter value has been
captured in TIMx_CCR1 register (an edge has been detected on IC1, as per the edge
sensitivity defined with the CC1P and CC1NP bits setting, in TIMx_CCER).
Bit 0 UIF: Update interrupt flag
This bit is set by hardware on an update event. It is cleared by software.
0: No update occurred.
1: Update interrupt pending. This bit is set by hardware when the registers are updated:
At overflow and if UDIS=’0 in the TIMx_CR1 register.
When CNT is reinitialized by software using the UG bit in TIMx_EGR register, if
URS=’0’ and UDIS=’0’ in the TIMx_CR1 register.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. CC1G UG
ww
