FD controller area network (FDCAN) RM0444

1214/1390 RM0444 Rev 5

Standard message ID filtering

Figure 399 shows the flow for standard Message ID (11-bit Identifier) filtering. The Standard

Message ID filter element is described in Section 36.3.8.

Controlled by the Global Filter Configuration (RXGFC) Message ID, Remote Transmission

Request bit (RTR), and the Identifier Extension bit (IDE) of received frames are compared

against the list of configured filter elements.

Figure 399. Standard Message ID filter path

MS47279V1

Valid frame received

Bit identifier

Remote frame

Receive filter list enabled

Match filter

element #0

non-matching

frames

Acceptance

or Rejection

Target FIFO full

Append to target FIFO

Match filter

element #RXGFC.LSS

Reject remote frame

Discard frame

11-bit 29-bit

Yes

RXGFC[LSS[7:0]] > 0

RXGFC[LSS[7:0]] = 0

RXGFC[RRFS] = 0

RXGFC[RRFS] = 1

RXGFC[ANFS[1]] = 1

RXGFC[ANFS[1]] = 0

Yes

Reject
