RM0444 DMA request multiplexer (DMAMUX)

313

6 EXTI LINE6 18 dmamux_evt2

7 EXTI LINE7 19 dmamux_evt3

8 EXTI LINE8 20 LPTIM1_OUT

9 EXTI LINE9 21 LPTIM2_OUT

10 EXTI LINE10 22 TIM14_OC

11 EXTI LINE11 23 Reserved

Table 54. DMAMUX: assignment of synchronization inputs to resources

Sync. input Resource Sync. input Resource

0 EXTI LINE0 12 EXTI LINE12

1 EXTI LINE1 13 EXTI LINE13

2 EXTI LINE2 14 EXTI LINE14

3 EXTI LINE3 15 EXTI LINE15

4 EXTI LINE4 16 dmamux_evt0

5 EXTI LINE5 17 dmamux_evt1

6 EXTI LINE6 18 dmamux_evt2

7 EXTI LINE7 19 dmamux_evt3

8 EXTI LINE8 20 LPTIM1_OUT

9 EXTI LINE9 21 LPTIM2_OUT

10 EXTI LINE10 22 TIM14_OC

11 EXTI LINE11 23 Reserved

Table 53. DMAMUX: assignment of trigger inputs to resources (continued)

Trigger input Resource Trigger input Resource
