RM0444 Rev 5 427/1390
RM0444 Digital-to-analog converter (DAC)
441
16.7.2 DAC software trigger register (DAC_SWTRGR)
Address offset: 0x04
Reset value: 0x0000 0000
Bits 5:2 TSEL1[3:0]: DAC channel1 trigger selection
These bits select the external event used to trigger DAC channel1
0000: SWTRIG1
0001: dac_ch1_trg1
0010: dac_ch1_trg2
...
1111: dac_ch1_trg15
Refer to the trigger selection tables in Section 16.4.2: DAC pins and internal signals for
details on trigger configuration and mapping.
Note: Only used if bit TEN1 = 1 (DAC channel1 trigger enabled).
Bit 1 TEN1: DAC channel1 trigger enable
This bit is set and cleared by software to enable/disable DAC channel1 trigger.
0: DAC channel1 trigger disabled and data written into the DAC_DHR1 register are
transferred one dac_pclk clock cycle later to the DAC_DOR1 register
1: DAC channel1 trigger enabled and data from the DAC_DHR1 register are transferred
three dac_pclk clock cycles later to the DAC_DOR1 register
Note: When software trigger is selected, the transfer from the DAC_DHR1 register to the
DAC_DOR1 register takes only one dac_pclk clock cycle.
Bit 0 EN1: DAC channel1 enable
This bit is set and cleared by software to enable/disable DAC channel1.
0: DAC channel1 disabled
1: DAC channel1 enabled
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. SWTRIG2 SWTRIG1
