Cyclic redundancy check calculation unit (CRC) RM0444

342/1390 RM0444 Rev 5

14.4.6 CRC register map

Refer to Section 2.2 on page 58 for the register boundary addresses.

Table 67. CRC register map and reset values

Offset

name

0x00

CRC_DR DR[31:0]

Reset value

11111111111111111111111111111111

0x04

CRC_IDR IDR[31:0]

Reset value

00000000000000000000000000000000

0x08

CRC_CR

Res.

REV_OUT

REV_IN[1:0]

POLYSIZE[1:0]

Res.

RESET

Reset value 00000 0

0x10

CRC_INIT CRC_INIT[31:0]

Reset value 11111111111111111111111111111111

0x14

CRC_POL POL[31:0]

Reset value 00000100110000010001110110110111
