RM0444 Rev 5 615/1390
RM0444 Advanced-control timer (TIM1)
624
21.4.25 TIM1 capture/compare register 5 (TIM1_CCR5)
Address offset: 0x58
Reset value: 0x0000 0000
Bits 31:25 Reserved, must be kept at reset value.
Bits 23:17 Reserved, must be kept at reset value.
Bit 15 OC6CE: Output compare 6 clear enable
Refer to OC1CE description.
Bits 24, 14, 13, 12 OC6M[3:0]: Output compare 6 mode
Refer to OC1M description.
Bit 11 OC6PE: Output compare 6 preload enable
Refer to OC1PE description.
Bit 10 OC6FE: Output compare 6 fast enable
Refer to OC1FE description.
Bits 9:8 Reserved, must be kept at reset value.
Bit 7 OC5CE: Output compare 5 clear enable
Refer to OC1CE description.
Bits 16, 6, 5, 4 OC5M[3:0]: Output compare 5 mode
Refer to OC1M description.
Bit 3 OC5PE: Output compare 5 preload enable
Refer to OC1PE description.
Bit 2 OC5FE: Output compare 5 fast enable
Refer to OC1FE description.
Bits 1:0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GC5C3 GC5C2 GC5C1 Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
rw rw rw
1514131211109876543210
CCR5[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
