Universal serial bus full-speed host/device interface (USB) RM0444

1282/1390 RM0444 Rev 5

Table 223. Resume event detection for host

[RXDP,RXDM] status Wakeup event Required resume software action

“00” Not allowed (noise on bus) Go back in Suspend mode

“10”

Full speed capable device:

Not allowed (noise on bus)

Low speed device: Device

remote wakeup resume

None

“01”

Full speed capable device:

Device remote wakeup

resume

Low speed device:

Not allowed (noise on bus)

None

“11” Not allowed (noise on bus) Go back in Suspend mode
