RM0444 Rev 5 99/1390

RM0444 Embedded Flash memory (FLASH)

118

Table 23. FLASH interrupt requests

Interrupt event Event flag

Event flag/interrupt

clearing method

Interrupt enable

control bit

End of operation EOP

(1)

Write EOP=1 EOPIE

Operation error OPERR

(2)

Write OPERR=1 ERRIE

Read protection error RDERR Write RDERR=1 RDERRIE

Write protection error WRPERR Write WRPERR=1 N/A

Size error SIZERR Write SIZERR=1 N/A

Programming sequential error PROGERR Write PROGERR=1 N/A

Programming alignment error PGAERR Write PGAERR=1 N/A

Programming sequence error PGSERR Write PGSERR=1 N/A

Data miss during fast programming error MISSERR Write MISSERR=1 N/A

Fast programming error FASTERR Write FASTERR=1 N/A

ECC error correction ECCC Write ECCC=1 ECCCIE

ECC double error (NMI) ECCD Write ECCD=1 N/A

1. EOP is set only if EOPIE is set.

2. OPERR is set only if ERRIE is set.
