ST STM32G0 1 Series - Table 91. COMP1 Inverting Input Assignment; Table 92. COMP2 Non-Inverting Input Assignment; Table 93. COMP2 Inverting Input Assignment

To Next Page

To Previous Page

RM0444 Rev 5 447/1390

RM0444 Comparator (COMP)

458

Table 91. COMP1 inverting input assignment

COMP1_INM COMP1_INMSEL[3:0]

¼ V

REFINT

0000

½ V

REFINT

0001

¾ V

REFINT

0010

REFINT

0011

DAC Channel1 0100

DAC Channel2 0101

PB1 0110

PC4 0111

PA0 1000

¼ V

REFINT

> 1000

Table 92. COMP2 non-inverting input assignment

COMP2_INP COMP2_INPSEL[1:0]

PB4 00

PB6 01

PA3 10

Open 11

Table 93. COMP2 inverting input assignment

COMP2_INM COMP2_INMSEL[3:0]

¼ V

REFINT

0000

½ V

REFINT

0001

¾ V

REFINT

0010

REFINT

0011

DAC Channel1 0100

DAC Channel2 0101

PB3 0110

PB7 0111

PA2 1000

¼ V

REFINT

> 1000
