HDMI-CEC controller (CEC) RM0444

1356/1390 RM0444 Rev 5

39.6 HDMI-CEC interrupts

An interrupt can be produced:

• during reception if a receive block transfer is finished or if a receive error occurs.

• during transmission if a transmit block transfer is finished or if a transmit error occurs.

02.75

The latest time for the start of a following bit.

12.95

Table 244. TXERR timing parameters (continued)

Time RXTOL ms Description

Table 245. HDMI-CEC interrupts

Interrupt event Event flag Enable control bit

Rx-byte received

RXBR RXBRIE

End of reception

RXEND RXENDIE

Rx-overrun

RXOVR RXOVRIE

Rxbit rising error

BRE BREIE

Rx-short bit period error

SBPE SBPEIE

Rx-long bit period error

LBPE LBPEIE

Rx-missing acknowledge error

RXACKE RXACKEIE

Arbitration lost

ARBLST ARBLSTIE

Tx-byte request

TXBR TXBRIE

End of transmission

TXEND TXENDIE

Tx-buffer underrun

TXUDR TXUDRIE

Tx-error

TXERR TXERRIE

Tx-missing acknowledge error

TXACKE TXACKEIE
