Comparator (COMP) RM0444

458/1390 RM0444 Rev 5

18.6.4 COMP register map

The following table summarizes the comparator registers.

The comparator registers share SYSCFG peripheral register base addresses.

Refer to Section 2.2 on page 58 for the register boundary addresses.

Table 98. COMP register map and reset values

Offset Register

0x00

COMP1_CSR

LOCK

VALUE

Res.

BLANKSEL[4:0]

PWRMODE[1:0]

HYST

POL

WINOUT

Res.

WINMODE

Res.

INPSEL[1:0].

INMSEL[3:0]

Res.

Reset value 00 00000000000 0 000000 0

0x04

COMP2_CSR

LOCK

VALUE

Res.

BLANKSEL[4:0]

PWRMODE[1:0]

HYST

POL

WINOUT

Res.

WINMODE

Res.

INPSEL[1:0].

INMSEL[3:0]

Res.

Reset value 00 00000000000 0 000000 0

0x08

COMP3_CSR

LOCK

VALUE

Res.

BLANKSEL[4:0]

PWRMODE[1:0]

HYST

POL

WINOUT

Res.

WINMODE

Res.

INPSEL[1:0].

INMSEL[3:0]

Res.

Reset value 00 00000000000 0 000000 0
