DocID024597 Rev 3 1115/1693
RM0351 Inter-integrated circuit (I2C) interface
1177
If NOSTRETCH=1 in slave mode, the SCL is not stretched. Consequently the SDADEL
must be programmed in such a way to guarantee also a sufficient setup time.
Additionally, in master mode, the SCL clock high and low levels must be configured by
programming the PRESC[3:0], SCLH[7:0] and SCLL[7:0] bits in the I2C_TIMINGR register.
• When the SCL falling edge is internally detected, a delay is inserted before releasing
the SCL output. This delay is
t
SCLL
= (SCLL+1) x t
PRESC
where t
PRESC
= (PRESC+1) x
t
I2CCLK.
t
SCLL
impacts the SCL low time t
LOW .
• When the SCL rising edge is internally detected, a delay is inserted before forcing the
SCL output to low level. This delay is
t
SCLH
= (SCLH+1) x t
PRESC
where t
PRESC
=
(PRESC+1) x t
I2CCLK.
t
SCLH
impacts the SCL high time t
HIGH .
Refer to I2C master initialization for more details.
Caution: Changing the timing configuration is not allowed when the I2C is enabled.
The I2C slave NOSTRETCH mode must also be configured before enabling the peripheral.
Refer to I2C slave initialization for more details.
Caution: Changing the NOSTRETCH configuration is not allowed when the I2C is enabled.
Table 177. I
2
C-SMBUS specification data setup and hold times
Symbol Parameter
Standard-mode
(Sm)
Fast-mode
(Fm)
Fast-mode Plus
(Fm+)
SMBUS
Unit
Min. Max Min. Max Min. Max Min. Max
t
HD;DAT
Data hold time 0-0-0 -0.3-
µs
t
VD;DAT
Data valid time - 3.45 - 0.9 - 0.45 - -
t
SU;DAT
Data setup time 250 - 100 50 250
ns
t
r
Rise time of both SDA
and SCL signals
- 1000 300 - 120 - 1000
t
f
Fall time of both SDA
and SCL signals
- 300 300 - 120 - 300
