SD/SDIO/MMC card host interface (SDMMC) RM0351
1436/1693 DocID024597 Rev 3
Note: 1 While the SD/SDIO card or MultiMediaCard is in identification mode, the SDMMC_CK
frequency must be less than 400 kHz.
2 The clock frequency can be changed to the maximum card bus frequency when relative
card addresses are assigned to all cards.
3 After a data write, data cannot be written to this register for three SDMMCCLK clock periods
plus two PCLK2 clock periods. SDMMC_CK can also be stopped during the read wait
interval for SD I/O cards: in this case the SDMMC_CLKCR register does not control
SDMMC_CK.
1514131211109876543210
Res.
HWFC
_EN
NEGE
DGE
WID
BUS
BYPAS
S
PWRS
AV
CLKEN CLKDIV
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:15 Reserved, must be kept at reset value.
Bit 14 HWFC_EN: HW Flow Control enable
0b: HW Flow Control is disabled
1b: HW Flow Control is enabled
When HW Flow Control is enabled, the meaning of the TXFIFOE and RXFIFOF interrupt
signals, please see SDMMC Status register definition in Section 41.8.11.
Bit 13 NEGEDGE: SDMMC_CK dephasing selection bit
0b: Command and Data changed on the SDMMCCLK falling edge succeeding the rising
edge of SDMMC_CK. (SDMMC_CK rising edge occurs on SDMMCCLK rising edge).
1b: Command and Data changed on the SDMMC_CK falling edge.
When BYPASS is active, the data and the command change on SDMMCCLK falling edge
whatever NEGEDGE value.
Bits 12:11 WIDBUS: Wide bus mode enable bit
00: Default bus mode: SDMMC_D0 used
01: 4-wide bus mode: SDMMC_D[3:0] used
10: 8-wide bus mode: SDMMC_D[7:0] used
Bit 10 BYPASS: Clock divider bypass enable bit
0: Disable bypass: SDMMCCLK is divided according to the CLKDIV value before driving the
SDMMC_CK output signal.
1: Enable bypass: SDMMCCLK directly drives the SDMMC_CK output signal.
Bit 9 PWRSAV: Power saving configuration bit
For power saving, the SDMMC_CK clock output can be disabled when the bus is idle by
setting PWRSAV:
0: SDMMC_CK clock is always enabled
1: SDMMC_CK is only enabled when the bus is active
Bit 8 CLKEN: Clock enable bit
0: SDMMC_CK is disabled
1: SDMMC_CK is enabled
Bits 7:0 CLKDIV: Clock divide factor
This field defines the divide factor between the input clock (SDMMCCLK) and the output
clock (SDMMC_CK): SDMMC_CK frequency = SDMMCCLK / [CLKDIV + 2].
