USB on-the-go full-speed (OTG_FS) RM0351
1540/1693 DocID024597 Rev 3
43.15.10 OTG Host non-periodic transmit FIFO size register
(OTG_HNPTXFSIZ)/Endpoint 0 Transmit FIFO size
(OTG_DIEPTXF0)
Address offset: 0x028
Reset value: 0x0200 0200
Host mode
Device mode
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 RXFD: Rx FIFO depth
This value is in terms of 32-bit words.
Minimum value is 16
Programmed values must respect the available FIFO memory allocation and must not
exceed the power-on value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
NPTXFD/TX0FD
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
NPTXFSA/TX0FSA
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:16 NPTXFD: Non-periodic Tx FIFO depth
This value is in terms of 32-bit words.
Minimum value is 16
Programmed values must respect the available FIFO memory allocation and must not
exceed the power-on value.
Bits 15:0 NPTXFSA: Non-periodic transmit RAM start address
This field configures the memory start address for non-periodic transmit FIFO RAM.
Bits 31:16 TX0FD: Endpoint 0 Tx FIFO depth
This value is in terms of 32-bit words.
Minimum value is 16
Programmed values must respect the available FIFO memory allocation and must not
exceed the power-on value.
Bits 15:0 TX0FSA: Endpoint 0 transmit RAM start address
This field configures the memory start address for the endpoint 0 transmit FIFO RAM.
