1. On the [Start] menu, select [Control Panel]. Then select [Printers and Other Hardware],
and then [Printers and Faxes].
In Windows XP Professional or Windows Server 2003/2003 R2, select [Printers and Faxes] on the
[Start] menu.
In Windows Vista or Windows Server 2008, select [Control Panel] on the [Start] menu. Then select
[Hardware and Sound], and then [Printers].
In Windows 7 or Windows Server 2008 R2, select [Devices and Printers] on the [Start] menu.
2. Select to highlight [LAN-Fax M8], then click [Properties] on the [File] menu.
In Windows 7 or Windows Server 2008 R2, right click the [LAN-Fax M8], and then click [Printer
Properties].
3. Click the [Accessories] tab, and then make the settings for the option configuration.
4. Select the check boxes for the installed optional units.
5. Click [Apply].
Option configuration settings are complete.
6. Click [OK].
[Accessories] tab
The [Accessories] tab contains the following items besides option configuration items:
•
Prohibit manual destination entry
Check this option to prohibit direct specification of destinations.
• Enable E-mail
Check this when using Internet Fax with the LAN-Fax function.
• IP-Fax
Check this option when using IP-Fax.
After checking this option, select a protocol by clicking an appropriate radio button.
• If the options on this machine are not configured as instructed, LAN-Fax functions may fail.
•
If this machine is connected to a network and SmartDeviceMonitor for Client is installed on your
computer, configuration of each option installed on the machine will be performed automatically. If
the settings do not match the installed optional units, click [Load from Device].
Basic Transmission
This section explains how to send fax documents created using Windows applications.
To send a fax, simply select [Print...] from the Windows application, then select [LAN-Fax M8] as the
printer, and then specify a destination in the [LAN-Fax] dialog box.
6. Fax via Computer
324
