Print Area
The following shows the print area for this machine. Be sure to set the print margins correctly by the
application.
1. Print area
2.
Feed direction
3. 1.0 to 5.0 mm (0.04 to 0.20 inches)
4. 0.5 mm (0.02 inches) or more
5. 0.5 to 4.5 mm (0.02 to 0.18 inches)
6. 0.5 to 3.5 mm (0.02 to 0.14 inches)
• The print area may vary depending on the paper size, printer language and printer driver settings.
•
When [Edge to Edge Print] under [System] in [Printer Features] is enabled, margins on the left and
right will become 2 mm.
• p.153 "System"
Print Area
67
