• If you cannot identify the printer you want to configure, check the printer name against the
configuration page printed from the printer.
•
If no printer names appear in the list, match the frame types of IPX/SPXs for the computer and
printer. Use the [Network] dialog box of Windows to change the frame type of the computer.
• For details about Web Image Monitor, see "Using Web Image Monitor".
• For details about login user names and passwords, see Security Reference, which is the
administrator's manual.
• p.131 "Using Web Image Monitor"
Setting Up as a Remote Printer
To configure the printer as a remote printer, follow the procedure below.
• If you want to use the printer as a remote printer, set it to NDS mode.
•
Do not use the printer as a remote printer when Pure IP is used.
Setting up using NWadmin
1. From Windows, start NWadmin.
For details about NWadmin, see the NetWare manuals.
2. Set up the network connection to a print queue. Select the object in which the print queue
is located in the directory tree, and then click [Create] on the [Object] menu.
3. In the [Class of new object] box, click [Print Queue], and then click [OK].
4. In the [Print Queue Name] box, enter the name of the print queue.
5. In the [Print Queue Volume] box, click [Browse].
6. In the [Available objects] box, click the volume in which the print queue is created, and
then click [OK].
7. Check the settings, and then click [Create].
8. Set up the network connection to a printer. Select the object in which the printer is located,
and then click [Create] on the [Object] menu.
9. In the [Class of new object] box, click [Printer], and then click [OK].
10. In the [Printer name] box, enter the printer name.
11. Select the [Define additional properties] check box, and then click [Create].
3. Using a Printer Server
128
