Frequency range:
2412 - 2462 MHz (1 - 11 channels)
5180 - 5240 MHz (36, 40, 44 and 48 channels)
Default: [11]
Security Method
Specifies the encryption of the Wireless LAN.
Default: [Off]
If you select [WEP], always enter WEP key. If you select [WPA], specify the encryption and
authentication methods.
Specify "WPA", when [Communication Mode] is set to [Infrastructure Mode].
•
WEP
If you select [WEP], enter WEP key.
When using 64 bit WEP, up to 10 characters can be used for hexadecimal and up to 5
characters for ASCII. When using 128 bit WEP, up to 26 characters can be used for
hexadecimal and up to 13 characters for ASCII.
The number of characters that can be entered is limited to 10 or 26 for hexadecimal and 5 or
13 for ASCII.
• WPA
• WPA Encryption Method
Select either [TKIP] or [CCMP (AES)].
• WPA Authent. Method
Select either [WPA-PSK], [WPA], [WPA2-PSK], or [WPA2].
If you select [WPA-PSK] or [WPA2-PSK], enter the pre-shared key (PSK) of 8- 63
characters in ASCII code.
When [WPA] or [WPA2] are selected, authentication settings and certificate installation
settings are required. For details about setting methods, see "Configuring IEEE 802.1X".
Wireless LAN Signal
When using in infrastructure mode, you can check the machine's radio wave status using the
control panel.
Radio wave status is displayed when you press [Wireless LAN Signal].
Restore Factory Defaults
You can return the wireless LAN settings to their defaults.
• For details on how to access System Settings, see "Accessing User Tools".
1. System Settings
40
