• Enter the separate setting number [1-4] or [default] and specify the SPI input and output
values.
•
Specify a decimal number between 256-4095, for both the SPI input and output values.
Encapsulation mode setting
msh> ipsec manual {1|2|3|4|default} mode {transport|tunnel}
• Enter the separate setting number [1-4] or [default] and specify the encapsulation mode.
• To specify transport mode, enter [transport]. To specify tunnel mode, enter [tunnel].
• If you have set the address type in the default setting to [any], you cannot use [tunnel] in
encapsulation mode.
• Not specifying an encapsulation mode displays the current setting.
Tunnel end point setting
msh> ipsec manual {1|2|3|4|default} tunneladdar beginning IP address ending IP
address
• Enter the separate setting number [1-4] or [default] and specify the tunnel end point beginning
and ending IP address.
• Not specifying either the beginning or ending address displays the current settings.
Authentication algorithm and authentication key settings
msh> ipsec manual {1|2|3|4|default} auth {hmac-md5|hmac-sha1} authentication
key
• Enter the separate setting number [1-4] or [default] and specify the authentication algorithm,
and then set the authentication key.
• If you are setting a hexadecimal number, attach 0x at the beginning.
• If you are setting an ASCII character string, enter it as is.
• Not specifying either the authentication algorithm or key displays the current setting. (The
authentication key is not displayed.)
Encryption algorithm and encryption key setting
msh> ipsec manual {1|2|3|4|default} encrypt {null|des|3des|aes128|aes192|
aes256} encryption key
• Enter the separate setting number [1-4] or [default], specify the encryption algorithm, and
then set the encryption key.
• If you are setting a hexadecimal number, attach 0x at the beginning. If you have set the
encryption algorithm to [null], enter an encryption key of arbitrary numbers 2-64 digits long.
• If you are setting an ASCII character string, enter it as is. If you have set the encryption
algorithm to [null], enter an encryption key of arbitrary numbers 1-32 digits long.
• Not specifying an encryption algorithm or key displays the current setting. (The encryption key
is not displayed.)
