• Not specifying a security policy displays the current setting.
Security protocol setting
msh> ipsec ike {1|2|3|4|default} proto {ah|esp|dual}
• Enter the separate setting number [1-4] or [default] and specify the security protocol.
• To specify AH, enter [ah]. To specify ESP, enter [esp]. To specify AH and ESP, enter [dual].
• Not specifying a protocol displays the current setting.
IPsec requirement level setting
msh> ipsec ike {1|2|3|4|default} level {require|use}
• Enter the separate setting number [1-4] or [default] and specify the IPsec requirement level.
• If you specify [require], data will not be transmitted when IPsec cannot be used. If you specify
[use], data will be sent normally when IPsec cannot be used. When IPsec can be used, IPsec
transmission is performed.
• Not specifying a requirement level displays the current setting.
Encapsulation mode setting
msh> ipsec ike {1|2|3|4|default} mode {transport|tunnel}
• Enter the separate setting number [1-4] or [default] and specify the encapsulation mode.
• To specify transport mode, enter [transport]. To specify tunnel mode, enter [tunnel].
• If you have set the address type in the default setting to [any], you cannot use [tunnel] in
encapsulation mode.
• Not specifying an encapsulation mode displays the current setting.
Tunnel end point setting
msh> ipsec ike {1|2|3|4|default} tunneladdar beginning IP address ending IP
address
• Enter the separate setting number [1-4] or [default] and specify the tunnel end point beginning
and ending IP address.
• Not specifying either the beginning or ending address displays the current setting.
IKE partner authentication method setting
msh> ipsec ike {1|2|3|4|default} auth {psk|rsasig}
• Enter the separate setting number [1-4] or [default] and specify the authentication method.
• Specify [psk] to use a shared key as the authentication method. Specify [rsasig] to use a
certificate at the authentication method.
• You must also specify the PSK character string when you select [psk].
• Note that if you select "Certificate", the certificate for IPsec must be installed and specified
before it can be used. To install and specify the certificate use Web Image Monitor.
