9. Click [Close].
If installation is successful, the icon of the printer connected to the WSD port is added to the
[Printers] window.
• The port name that follows "WSD" uses random character strings. It cannot be changed freely.
•
To stop installation of the selected driver, click [Cancel] before the installation is complete. When
re-installing the WSD Port, right-click the machine's icon in the [Network] window, and then click
[Uninstall].
Windows 7, Windows Server 2008 R2 - WSD port
1. Quit all applications currently running.
2. On the [Start] menu, click [Computer].
3. Click [Network].
4. Right-click the machine's icon, and then click [Install].
Driver installation starts automatically.
If the "Device driver software was not successfully installed" message appears, close the message,
and then proceed to step 5.
5. On the [Start] menu, click [Devices and Printers].
6. Click [Add a printer].
7. Click [Add a local printer].
8. Check the [Use an existing port:] check box, and select WSD port.
9. Click [Next].
10. Click [Have Disk...].
11. Insert the CD-ROM into the CD-ROM drive.
If the [AutoPlay] dialog box appears, click the [Close] button.
12. Click [Browse...], and then specify a location for the printer driver.
If the CD-ROM drive is D, the source files of the printer driver are stored in the following locations:
•
PCL 5e
• 32bit-driver
D:\X86\DRIVERS\PCL5E\XP_VISTA\(language)\DISK1
• 64bit-driver
D:\X64\DRIVERS\PCL5E\X64\(language)\DISK1
• PCL 6
• 32bit-driver
Installing the Printer Driver for the Selected Port
27
