User manual Rev. 3 — 19 December 2013 21 of 841

NXP Semiconductors

UM10360

Chapter 3: LPC176x/5x System control

Fig 5. Example of start-up after reset

valid threshold

processor status

DD(REG)(3V3)

IRC status

RESET

GND

60 μs

1 μs; IRC stability count

boot time

user code

boot code

execution

finishes;

user code starts

flash read

starts

flash read

finishes

IRC

starts

IRC

stable

supply ramp-up

time

7 μs 181 μs 224 μs
