RM0444 USB Type-C™ / USB Power Delivery interface (UCPD)

1346

D 1101 11011 hex data D

E 1110 11100 hex data E

F 1111 11101 hex data F

Sync-1 K-code 11000 Startsynch #1

Sync-2 K-code 10001 Startsynch #2

RST-1 K-code 00111 Hard Reset #1

RST-2 K-code 11001 Hard Reset #2

EOP K-code 01101 EOP

Reserved Error 00000 Do Not Use

Reserved Error 00001 Do Not Use

Reserved Error 00010 Do Not Use

Reserved Error 00011 Do Not Use

Reserved Error 00100 Do Not Use

Reserved Error 00101 Do Not Use

Sync-3 K-code 00110 Startsynch #3

Reserved Error 01000 Do Not Use

Reserved Error 01100 Do Not Use

Reserved Error 10000 Do Not Use

Reserved Error 11111 Do Not Use

Table 233. 4b5b Symbol Encoding Table (continued)

Name 4b 5b Symbol description
