RM0444 Rev 5 791/1390
RM0444 General-purpose timers (TIM15/TIM16/TIM17)
830
corresponding CCxS bits. All the other bits of this register have a different function in input
and in output mode.
Output compare mode:
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res.
OC2M
[3]
Res. Res. Res. Res. Res. Res. Res.
OC1M
[3]
rw rw
1514131211109876543210
Res. OC2M[2:0]
OC2
PE
OC2
FE
CC2S[1:0] Res. OC1M[2:0]
OC1
PE
OC1
FE
CC1S[1:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:25 Reserved, must be kept at reset value.
Bits 23:17 Reserved, must be kept at reset value.
Bit 15 Reserved, must be kept at reset value.
Bits 24, 14:12 OC2M[3:0]: Output Compare 2 mode
Bit 11 OC2PE: Output Compare 2 preload enable
Bit 10 OC2FE: Output Compare 2 fast enable
Bits 9:8 CC2S[1:0]: Capture/Compare 2 selection
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC2 channel is configured as output.
01: CC2 channel is configured as input, IC2 is mapped on TI2.
10: CC2 channel is configured as input, IC2 is mapped on TI1.
11: CC2 channel is configured as input, IC2 is mapped on TRC. This mode is working only if
an internal trigger input is selected through the TS bit (TIMx_SMCR register)
Note: CC2S bits are writable only when the channel is OFF (CC2E = ‘0’ in TIMx_CCER).
Bit 7 Reserved, must be kept at reset value.
