ST STM32L4x6 User Manual

DocID024597 Rev 3 69/1693
RM0351
77
APB2
0x4001 4800 - 0x4001 4BFF 1 KB TIM17
Section 28.6.20: TIM16&TIM17
register map
0x4001 4400 - 0x4001 47FF 1 KB TIM16
Section 28.6.20: TIM16&TIM17
register map
0x4001 4000 - 0x4001 43FF 1 KB TIM15
Section 28.6.20: TIM16&TIM17
register map
0x4001 3C00 - 0x4001 3FFF 1KB Reserved -
0x4001 3800 - 0x4001 3BFF 1 KB USART1
Section 36.8.12: USART
register map
0x4001 3400 - 0x4001 37FF 1 KB TIM8
Section 26.4.31: TIM8 register
map
0x4001 3000 - 0x4001 33FF 1 KB SPI1 Section 38.6.8: SPI register map
0x4001 2C00 - 0x4001 2FFF 1 KB TIM1
Section 26.4.30: TIM1 register
map
0x4001 2800 - 0x4001 2BFF 1 KB SDMMC1
Section 41.8.16: SDMMC
register map
0x4001 2000 - 0x4001 27FF 2KB Reserved -
0x4001 1C00 - 0x4001 1FFF 1 KB FIREWALL
Section 4.4.8: Firewall register
map
0x4001 0800- 0x4001 1BFF 5KB Reserved -
0x4001 0400 - 0x4001 07FF 1 KB EXTI
Section 12.5.13: EXTI register
map
0x4001 0200 - 0x4001 03FF
1 KB
COMP
Section 19.6.3: COMP register
map
0x4001 0030 - 0x4001 01FF VREFBUF
Section 18.3.3: VREFBUF
register map
0x4001 0000 - 0x4001 002F SYSCFG
Section 8.2.11: SYSCFG
register map
Table 1. STM32L4x6 memory map and peripheral register boundary addresses (continued)
Bus Boundary address Size (bytes) Peripheral Peripheral register map
