• A message appears if there is a newer version of the printer driver already installed. If there is, you
cannot install the printer driver using Auto Run. If you still want to install the printer driver, use [Add
Printer]. See "Messages Displayed When Installing the Printer Driver", Troubleshooting.
Installing the PCL printer driver (IPP)
1. Quit all applications currently running.
2. Insert the CD-ROM into the CD-ROM drive.
The installer starts.
3. Select an interface language, and then click [OK].
4. Click [PCL Printer Driver].
The software license agreement appears in the [License Agreement] dialog box.
5. After reading the agreement, click [I accept the agreement.], and then click [Next >].
6. Select a printer driver you want to use in the [Select Program] dialog box.
You can select several printer drivers.
The PCL 6 printer driver is installed in the language specified by your operating system.
7. Click [Next >].
8. Select the machine model you want to use.
The machine name can be changed in the [Change settings for 'Printer Name'] box.
9. Double-click the machine name to display the printer settings.
The details shown in [Comment], [Driver], and [Port] vary depending on the operating system,
machine model, and port.
10. Click [Port], and then click [Add].
11. Click [SmartDeviceMonitor], and then click [OK].
12. Click [IPP].
13. In the [Printer URL] box, enter "http://(machine's IP address or host name)/printer" as
the machine's address.
If the server authentication is issued, to enable SSL (a protocol for encrypted communication), enter
"https://(machine's IP address or host name)/printer" (Internet Explorer 5.01, or a higher version
must be installed).
(example IP address: 192.168.15.16)
http://192.168.15.16/printer
https://192.168.15.16/printer
You can enter "http://machine's IP address or host name/ipp" as the machine's address.
1. Preparing the Machine
30
