If the address is "192.168.001.010", you must enter it as "192.168.1.10" to connect to the
machine.
14. Enter a name for identifying the printer in [IPP Port Name]. Use a name different from the
one of any existing ports.
If a name is not specified here, the address entered in the [Printer URL] box becomes the IPP port
name.
15. Click [Detailed Settings] to make necessary settings, and then click [OK].
For details about the settings, see SmartDeviceMonitor for Client Help.
16. Click [OK].
17. Check that the port of the selected printer is displayed in [Port].
18. Set a user code, if necessary.
Up to eight numeric characters can be entered. No alphabetic characters or symbols can be
entered.
19. Select the [Default Printer] check box to configure the printer as default.
20. Click [Continue].
Installation starts.
21. Click [Finish].
22. Select one of the options to restart the computer either now or later, and then click
[Finish].
Restart the computer to complete installation.
• To stop installation of the selected driver, click [Cancel] before installation is complete.
•
Auto Run may not work with certain operating system settings. In that case, launch "Setup.exe" on
the CD-ROM root directory.
• A message appears if there is a newer version of the printer driver already installed. If there is, you
cannot install the printer driver using Auto Run. If you still want to install the printer driver, use [Add
Printer]. See "Messages Displayed When Installing the Printer Driver", Troubleshooting.
Changing the port settings for SmartDeviceMonitor for Client
Follow the procedure below to change the SmartDeviceMonitor for Client settings, such as TCP/IP
timeout, recovery/parallel printing, and printer groups.
Windows XP, Windows Server 2003/2003 R2:
1. On the [Start] menu, click [Printers and Faxes].
The [Printers and Faxes] window appears.
Installing the Printer Driver for the Selected Port
31
