2. Click the icon of the printer you want to use. On the [File] menu, click [Properties].
3. Click the [Ports] tab, and then click [Configure Port...].
The [Port Configuration] dialog box appears.
Windows Vista, Windows Server 2008:
1. On the [Start] menu, click [Control Panel].
The [Control Panel] window appears.
2. Click [Printer] in "Hardware and Sound".
The [Printers] window appears.
3. Right-click the icon of the printer you want to use, and then click [Properties].
4. Click the [Ports] tab, and then click [Configure Port...].
The [Port Configuration:] dialog box appears.
Windows 7, Windows Server 2008 R2:
1. On the [Start] menu, click [Devices and Printers].
The [Devices and Printers] window appears.
2. Right-click the icon of the printer you want to use, and then click [Printer properties].
The printer properties appear.
3. Click the [Ports] tab, and then click [Configure Port...].
The [Port Configuration] dialog box appears.
• User, proxy, and timeout settings can be configured for IPP.
•
If no settings on the [Recovery/Parallel Printing] tab are available, follow the procedure below.
1. Click [Cancel] to close the [Port Configuration:] dialog box.
2. Start SmartDeviceMonitor for Client, and then right-click the SmartDeviceMonitor for Client
icon on the task tray.
3. Point to [Property], and then click [Extended Features Settings].
4. Select the [Set Recovery/Parallel Printing for each port] check box.
5. Click [OK] to close the [Extended Features Settings] dialog box.
• For details about these settings, see "Using the SmartDeviceMonitor for Client Port", or
SmartDeviceMonitor for Client Help.
• p.28 "Using the SmartDeviceMonitor for Client Port"
