4. Click [PostScript 3 Printer Driver].
Add Printer Wizard starts.
5. Click [Add a local printer].
6. Click [Create a new port:].
7. Click [SmartDeviceMonitor] in [Type of port:], and then click [Next].
8. Click [IPP].
9. In the [Printer URL] box, enter "http://(machine's IP address or host name)/printer" as
the machine's address.
If the server authentication is issued, to enable SSL (a protocol for encrypted communication), enter
"https://(machine's IP address or host name)/printer" (Internet Explorer 5.01, or a higher version
must be installed).
(example IP address: 192.168.15.16)
http://192.168.15.16/printer
https://192.168.15.16/printer
You can enter "http://machine's IP address or host name/ipp" as the machine's address.
If the address is "192.168.001.010", you must enter it as "192.168.1.10" to connect to the
machine.
10. Enter a name for identifying the machine in [IPP Port Name]. Use a name different from
the one of any existing port.
If a name is not specified here, the address entered in the [Printer URL] box becomes the IPP port
name.
11. Click [Detailed Settings] to make necessary settings, and then click [OK].
For information about the settings, see SmartDeviceMonitor for Client Help.
12. Click [OK].
13. Check that the name of the printer driver you want to install is selected, and then click
[Next].
14. Change the name of the machine if you want, and then click [Next].
If a check box for setting the machine as a default printer appears, configure as necessary.
15. Specify whether or not to share the machine, and then click [Next].
16. Specify whether or not to print a test page, and then click [Finish].
If a check box for setting the machine as a default printer appears, configure as necessary.
The printer driver installation starts.
• To stop installation of the selected driver, click [Cancel] before installation is complete.
1. Windows Configuration
26
