Table 3-4. Interrupt vector assignments (continued)
Address Vector IRQ
1
NVIC
non-IPR
register
number
2
NVIC
IPR
register
number
3
Source module Source description
0x0000_00DC 55 39 1 9 ADC0 —
0x0000_00E0 56 40 1 10 CMP0 —
0x0000_00E4 57 41 1 10 CMP1 —
0x0000_00E8 58 42 1 10 FTM0 Single interrupt vector for all sources
0x0000_00EC 59 43 1 10 FTM1 Single interrupt vector for all sources
0x0000_00F0 60 44 1 11 FTM2 Single interrupt vector for all sources
0x0000_00F4 61 45 1 11 — —
0x0000_00F8 62 46 1 11 RTC Alarm interrupt
0x0000_00FC 63 47 1 11 RTC Seconds interrupt
0x0000_0100 64 48 1 12 PIT Channel 0
0x0000_0104 65 49 1 12 PIT Channel 1
0x0000_0108 66 50 1 12 PIT Channel 2
0x0000_010C 67 51 1 12 PIT Channel 3
0x0000_0110 68 52 1 13 PDB —
0x0000_0114 69 53 1 13 USB OTG —
0x0000_0118 70 54 1 13 — —
0x0000_011C 71 55 1 13 — —
0x0000_0120 72 56 1 14 DAC0 —
0x0000_0124 73 57 1 14 MCG —
0x0000_0128 74 58 1 14 Low Power Timer —
0x0000_012C 75 59 1 14 Port control module Pin detect (Port A)
0x0000_0130 76 60 1 15 Port control module Pin detect (Port B)
0x0000_0134 77 61 1 15 Port control module Pin detect (Port C)
0x0000_0138 78 62 1 15 Port control module Pin detect (Port D)
0x0000_013C 79 63 1 15 Port control module Pin detect (Port E)
0x0000_0140 80 64 2 16 Software Software interrupt
4
0x0000_0144 81 65 2 16 — —
0x0000_0148 82 66 2 16 — —
0x0000_014C 83 67 2 16 — —
0x0000_0150 84 68 2 17 — —
0x0000_0154 85 69 2 17 — —
0x0000_0158 86 70 2 17 — —
0x0000_015C 87 71 2 17 FTM3 Single interrupt vector for all sources
0x0000_0160 88 72 2 18 DAC1 —
0x0000_0164 89 73 2 18 ADC1 —
1. Indicates the NVIC's interrupt source number.
Chapter 3 Chip Configuration
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 63
