Quality of Service Commands
288
M4100 Series ProSAFE Managed Switches
show class-map
This command displays all configuration information for the specified class. The
<class-name> is the name of an existing DiffServ class.
• Privileged EXEC
• User EXEC
If the class-name is specified, the fields that are shown in the following table are displayed.
If you do not specify the class name, this command displays a list of all defined DiffServ
classes.
The fields that are shown in the following table are displayed.
Format show class-map <class-name>
Modes
Term Definition
Class Name The name of this class.
Class Type A class type of ‘all’ means every match criterion defined for the class is evaluated
simultaneously and must all be true to indicate a class match.
Class Layer3
Protocol
The Layer 3 protocol for this class. Possible values are IPv4 and IPv6.
Match Criteria The Match Criteria fields are only displayed if they have been configured. Not all
platforms support all match criteria values. They are displayed in the order entered by
the user. The fields are evaluated in accordance with the class type. The possible Match
Criteria fields are: Destination IP Address, Destination Layer 4 Port, Destination MAC
Address, Ethertype, Source MAC Address, VLAN, Class of Service, Every, IP DSCP, IP
Precedence, IP TOS, Protocol Keyword, Reference Class, Source IP Address, and
Source Layer 4 Port.
Values The values of the Match Criteria.
Term Definition
Class Name The name of this class. (Note that the order in which classes are displayed is not
necessarily the same order in which they were created.)
Class Type A class type of ‘all’ means every match criterion defined for the class is evaluated
simultaneously and must all be true to indicate a class match.
Reference Class
Name
The name of an existing DiffServ class whose match conditions are being referenced by
the specified class definition.
