Switching Commands

129

M4100 Series ProSAFE Managed Switches

Static MAC Filtering Commands

The commands in this section describe how to configure static MAC filtering. Static MAC

filtering allows you to configure destination ports for a static multicast MAC filter irrespective

of the platform.

macfilter

This command adds a static MAC filter entry for the MAC address <macaddr> on the VLAN

<vlanid>. A packet with a specific destination MAC address in a specific VLAN is admitted

only if the ingress port is defined in the set of source ports, otherwise the packet is dropped.

On the egress side, a packet that was admitted is sent through all ports that are defined in

the set of destination ports.

The value of the <macaddr> parameter is a 6-byte hexadecimal number in the format of

b1:b2:b3:b4:b5:b6. The following MAC addresses are restricted: 00:00:00:00:00:00,

01:80:C2:00:00:00 to 01:80:C2:00:00:0F, 01:80:C2:00:00:20 to 01:80:C2:00:00:21, and

FF:FF:FF:FF:FF:FF. The <vlanid> parameter must identify a valid VLAN.

The number of static mac filters supported on the system is different for MAC filters where

source ports are configured and MAC filters where destination ports are configured.

• For unicast MAC address filters and multicast MAC address filters with source port lists,

the maximum number of static MAC filters supported is 20.

• For multicast MAC address filters with destination ports configured, the maximum number

of static filters supported is 256.

For example, for current platforms you can configure the following combinations:

• Unicast MAC and source port (max = 20)

• Multicast MAC and source port (max=20)

• Multicast MAC and destination port (only) (max=256)

• Multicast MAC and source ports and destination ports (max=20)

no macfilter

This command removes all filtering restrictions and the static MAC filter entry for the MAC

address <macaddr> on the VLAN <vlanid>. The <macaddr> parameter must be specified

as a 6-byte hexadecimal number in the format of b1:b2:b3:b4:b5:b6.

The <vlanid> parameter must identify a valid VLAN.

Format macfilter <macaddr> <vlanid>

Mode Global Config

Format no macfilter <macaddr> <vlanid>

Mode Global Config
