Green Ethernet Commands
526
M4100 Series ProSAFE Managed Switches
show green-mode
This command displays the green mode configuration and operational status either for the
whole system or for a port. This command can display the per-port configuration and
operational status of the green mode. The status is shown only for the modes supported on
the switch.
The following table shows the fields that display if you do not specify a slot and port.
The following table shows the fields that display if you specify a slot and port.
Format show green-mode [<slot/port>]
Mode Privileged Exec
Field Definition
Energy Detect
Energy-detect Config Energy-detect Admin mode is enabled or disabled
Energy-detect Opr Energy detect mode is currently active or inactive. The energy detect mode might be
administratively enabled, but the operational status might be inactive.
EEE
EEE Config EEE Admin Mode is enabled or disabled.
Global
Cumulative Energy
Saving per Stack
Estimated cumulative energy saved per stack in (watts * hours) due to all green
modes enabled
Current Power
Consumption per Stack
Power consumption by all ports in stack in mWatts.
Power Saving Estimated percentage power saved on all ports in stack due to green mode(s)
enabled.
Unit Unit index of the stack member
Green Ethernet Features
supported
List of green features supported on the unit which could be one or more of the
following: Energy-Detect (Energy Detect), Short-Reach (Short Reach), EEE (Energy
Efficient Ethernet), LPI-History (EEE Low Power Idle History), LLDP-Cap-Exchg
(EEE LLDP Capability Exchange), Pwr-Usg-Est (Power Usage Estimates).
Field Definition
Energy-detect admin
mode
Energy-detect mode is enabled or disabled.
Energy-detect
operational status
Energy detect mode is currently active or inactive. The energy detect mode might be
administratively enabled, but the operational status might be inactive. The reasons
for the same are described below.
