Routing Commands
251
M4100 Series ProSAFE Managed Switches
show routing heap summary
This command displays a summary of the memory allocation from the routing heap. The
routing heap is a chunk of memory set aside when the system boots for use by the routing
applications.
Command example:
(NETGEAR Switch) #show routing heap summary
Heap Size....................... 92594000 bytes
Memory In Use................... 149598 bytes (0%)
Memory on Free List............. 78721 bytes (0%)
Memory Available in Heap........ 92365249 bytes (99%)
In Use High Water Mark.......... 210788 bytes (0%)
Virtual LAN Routing Commands
This section describes the commands you use to view and configure VLAN routing and to
view VLAN routing status information.
vlan routing
This command enables routing on a VLAN. The vlanid value has a range from 1 to 4093. The
[interface ID] value has a range from 1 to 128. Typically, you will not supply the interface ID
argument, and the system automatically selects the interface ID. However, if you specify an
interface ID that is already in use, the CLI displays an error message and does not create the
VLAN interface.
Format show routing heap summary
Mode Privileged EXEC
Term Description
Heap Size The amount of memory, in bytes, allocated at startup for the routing heap.
Memory In Use The number of bytes currently allocated.
Memory on Free List The number of bytes currently on the free list. When a chunk of memory from the
routing heap is freed, it is placed on a free list for future reuse.
Memory Available in
Heap
The number of bytes in the original heap that have never been allocated.
In Use High Water
Mark
The maximum memory in use since the system last rebooted.
Format vlan routing <vlan-id> [interface id]
Mode VLAN Config
