Page #224 background imageLoading...
Page #224 background image
Multicast VLAN Registration Commands
224
M4100 Series ProSAFE Managed Switches
The following table explains the output parameters.
Command example:
(NETGEAR Switch)#show mvr
MVR Running…........................... TRUE
MVR multicast VLAN….................... 1200
MVR Max Multicast Groups….............. 256
MVR Current multicast groups….......... 1
MVR Global query response time…........ 10 (tenths of sec)
MVR Mode….............................. compatible
show mvr members
This command displays the MVR membership groups allocated. <A.B.C.D> is a valid
multicast address in IPv4 dotted notation.
The following table describes the output parameters.
Command example:
(NETGEAR Switch)#show mvr members
MVR Group IP Status Members
------------------ --------------- ---------------------
224.1.1.1 INACTIVE 0/1, 0/2, 0/3
Term Definition
MVR Running MVR running state. It can be enabled or disabled.
MVR multicast VLAN Current MVR multicast VLAN. It can be in the range from 1 to
4094.
MVR Max Multicast Groups The maximum number of multicast groups supported by MVR.
MVR Current multicast groups The current number of MVR groups allocated.
MVR Query response time The current MVR query response time.
MVR Mode The current MVR mode. It can be compatible or dynamic.
Format show mvr members [<A.B.C.D>]
Mode Privileged EXEC
Term Definition
MVR Group IP MVR group multicast IP address.
Status The status of the specific MVR group. It can be active or inactive.
Members The list of ports that participates in the specified MVR group.
