Page #289 background imageLoading...
Page #289 background image
Quality of Service Commands
289
M4100 Series ProSAFE Managed Switches
show diffserv
This command displays the DiffServ General Status Group information, which includes the
current administrative mode setting as well as the current and maximum number of rows in
each of the main DiffServ private MIB tables. This command provides no options.
show policy-map
This command displays all configuration information for the specified policy. The
<policyname> is the name of an existing DiffServ policy.
If the policy name is specified, the fields that are shown in the following table are displayed.
Format show diffserv
Mode Privileged EXEC
Term Definition
DiffServ Admin mode The current value of the DiffServ administrative mode.
Class Table Size
Current /Max
The current number of entries (rows) and the maximum allowed entries (rows) in
the Class Table.
Class Rule Table Size
Current /Max
The current number of entries (rows) and the maximum allowed entries (rows) in
the Class Rule Table.
Policy Table Size
Current /Max
The current number of entries (rows) and the maximum allowed entries (rows) in
the Policy Table.
Policy Instance Table
Size Current /Max
Current number of entries (rows) and the maximum allowed entries (rows) in the
Policy Instance Table.
Policy Attribute Table
Size Current /Max
Current number of entries (rows) and the maximum allowed entries (rows) in the
Policy Attribute Table.
Service Table Size
Current /Max
The current number of entries (rows) i and the maximum allowed entries (rows) in
the Service Table.
Format show policy-map [<policyname>]
Mode Privileged EXEC
Term Definition
Policy Name The name of this policy.
Policy Type The policy type (Only inbound policy definitions are supported for this platform.)
