Quality of Service Commands
280
M4100 Series ProSAFE Managed Switches
match vlan
This command adds to the specified class definition a match condition based on the value of
the layer 2 VLAN Identifier field (the 802.1Q tag of a VLAN tagged packet). The VLAN is an
integer from 0 to 4095.
• Class-Map Config
• Ipv6-Class-Map Config
match secondary-vlan
This command adds to the specified class definition a match condition based on the value of
the layer 2 secondary VLAN Identifier field (the 802.1Q tag of a double VLAN tagged packet).
The VLAN is an integer from 0 to 4095.
• Class-Map Config
• Ipv6-Class-Map Config
DiffServ Policy Commands
Use the DiffServ policy commands to specify traffic conditioning actions, such as policing and
marking, to apply to traffic classes
Use the policy commands to associate a traffic class that you define by using the class
command set with one or more QoS policy attributes. Assign the class/policy association to
an interface to form a service. Specify the policy name when you create the policy.
Each traffic class defines a particular treatment for packets that match the class definition.
Y
ou can associate multiple traffic classes with a single policy. When a packet satisfies the
conditions of more than one class, preference is based on the order in which you add the
classes to the policy. The first class you add has the highest precedence.
This set of commands consists of policy creation/deletion, class addition/removal, and
individual policy attributes.
Default none
Format match srcl4port {<portkey> | <0-65535>}
Mode • Class-Map Config
• Ipv6-Class-Map Config
Default none
Format match vlan <0-4095>
Mode
Default none
Format match secondary-vlan <0-4095>
Mode
