Quality of Service Commands
309
M4100 Series ProSAFE Managed Switches
Time Range Commands for Time-Based ACLs
Time-based ACLs allow one or more rules within an ACL to be based on time. Each ACL rule
within an ACL, except for the implicit deny all rule, can be configured to be active and
operational only during a specific time period. The time range commands allow you to define
specific times of the day and week to implement time-based ACLs. The time range is
identified by a name and can then be referenced by an ACL rule defined with in an ACL.
time-range
Use this command to create a time range identified by <name>, consisting of one absolute
time entry and/or one or more periodic time entries. The <name> parameter is a
case-sensitive, alphanumeric string from 1 to 31 characters that uniquely identifies the time
range. An alpha-numeric string is defined as consisting of only alphabetic, numeric, dash,
underscore, or space characters. If a time range by this name exists, this command enters
Time-Range config mode to allow updating the time range entries
Note: When you successfully execute this command, the CLI mode
changes to Time-Range Config mode.
no time-range
Use this command to delete a time-range identified by <name>.
Log Displays when you enable logging for the rule.
Assign Queue The queue identifier to which packets matching this rule are assigned.
Mirror Interface The slot/port to which packets matching this rule are copied.
Redirect
Interface
The slot/port to which packets matching this rule are forwarded.
Time Range
Name
Displays the name of the time-range if the IPv6 ACL rule has referenced a time range.
Rule Status Status (Active/Inactive) of the IPv6 ACL rule.
Format time-range <name>
Mode Global Config
Format no time-range <name>
Mode Global Config
Term Definition
