Page #177 background imageLoading...
Page #177 background image
Switching Commands
177
M4100 Series ProSAFE Managed Switches
no set mld querier election participate
Use this command to set the snooping querier not to participate in querier election, but go
into a non-querier mode as soon as it discovers the presence of another querier in the same
VLAN.
show mldsnooping querier
Use this command to display MLD Snooping Querier information. Configured information is
displayed whether or not MLD Snooping Querier is enabled.
When the optional arguments vlandid are not used, the command displays the following
information.
When you specify a value for vlanid, the following information appears.
Format no set mld querier election participate
Mode VLAN Config
Format show mldsnooping querier [{detail | vlan <vlanid>}]
Mode Privileged EXEC
Term Description
Admin Mode Indicates whether or not MLD Snooping Querier is active on the switch.
Admin Version Indicates the version of MLD that will be used while sending out the queries. This is
defaulted to MLD v1 and it cannot be changed.
Querier Address Shows the IP address which will be used in the IPv6 header while sending out MLD
queries. It can be configured using the appropriate command.
Query Interval Shows the amount of time in seconds that a Snooping Querier waits before sending
out the periodic general query.
Querier Timeout Displays the amount of time to wait in the Non-Querier operational state before moving
to a Querier state.
Term Description
VLAN Admin Mode Indicates whether MLD Snooping Querier is active on the VLAN.
VLAN Operational
State
Indicates whether MLD Snooping Querier is in “Querier” or “Non-Querier” state. When
the switch is in Querier state, it will send out periodic general queries. When in
Non-Querier state, it will wait for moving to Querier state and does not send out any
queries.
Operational Max
Response Time
Indicates the time to wait before removing a Leave from a host upon receiving a Leave
request. This value is calculated dynamically from the Queries received from the
network. If the Snooping Switch is in Querier state, then it is equal to the configured
value.
