Routing Commands
244
M4100 Series ProSAFE Managed Switches
show ip protocols
This command lists a summary of the configuration and status for each unicast routing
protocol. The command lists routing protocols that are configured and enabled. If a protocol
is selected on the command line, the display is limited to that protocol.
Term Definition
Interface Valid slot and port number separated by forward slashes.
State Routing operational state of the interface.
IP Address The IP address of the routing interface in 32-bit dotted decimal format.
IP Mask The IP mask of the routing interface in 32-bit dotted decimal format.
Netdir Bcast Indicates if IP forwards net-directed broadcasts on this interface. Possible values are
Enable or Disable.
MultiCast Fwd The multicast forwarding administrative mode on the interface. Possible values are
Enable or Disable.
Method Shows whether the IP address was configured manually or acquired from a DHCP
server.
Format show ip protocols [ospf | rip]
Mode Privileged EXEC
Parameter Description
OSPFv2
Router ID The router ID configured for OSPFv2
OSPF Admin Mode Whether OSPF is enabled or disabled globally
Maximum Paths The maximum number of next hops in an OSPF route
Routing for Networks The address ranges configured with an OSPF network command
Distance The administrative distance (or route preference) for intra-area, inter-area, and
external routes
Default Route
Advertise
Whether OSPF is configured to originate a default route
Always Whether default advertisement depends on having a default route in the common
routing table
Metric The metric configured to be advertised with the default route
Metric Type The metric type for the default route
Redist Source A type of routes that OSPF is redistributing
Metric The metric to advertise for redistributed routes of this type
