Quality of Service Commands
278
M4100 Series ProSAFE Managed Switches
denotes the bit positions in <tosbits> that are used for comparison against the IP TOS field
in a packet. For example, to check for an IP TOS value having bits 7 and 5 set and bit 1 clear,
where bit 7 is most significant, use a <tosbits> value of a0 (hex) and a <tosmask> of a2
(hex).
Note: The match ip dscp, match ip precedence, and match ip
tos commands provide alternative ways to specify a match criterion
for the same Service Type field in the IP header, but each command
requires a slightly different user notation.
Note: This “free form” version of the IP DSCP, IP precedence, and IP ToS
match specification gives you complete control when specifying which
bits of the IP Service Type field must be checked.
match protocol
This command adds to the specified class definition a match condition based on the value of
the IP Protocol field in a packet using a single keyword notation or a numeric value notation.
To specify the match condition using a single keyword notation, the value for
<protocol-name> is one of the supported protocol name keywords. The currently
supported values are: icmp, igmp, ip, tcp, udp. A value of ip matches all protocol number
values.
To specify the match condition using a numeric value notation, the protocol number is a
standard value assigned by IANA and is interpreted as an integer from 0 to 255.
Note: This command does not validate the protocol number value against
the current list defined by IANA.
• Class-Map Config
• Ipv6-Class-Map Config
Default none
Format match ip tos <tosbits> <tosmask>
Mode
Class-Map Config
Default none
Format match protocol {<protocol-name> | <0-255>}
Mode
