Utility Commands

416

M4100 Series ProSAFE Managed Switches

The parameters that are shown in the following table are displayed in the trace message.

• HELLO. Hello packet

• DB_DSCR. Database descriptor

• LS_REQ. LS Request

• LS_UPD. LS Update

• LS_ACK. LS

Acknowledge

The remaining fields in the trace message are specific to the OSPF packets.

For HELLO packet field definitions, the parameters that are shown in the following table are

displayed in the trace message.

For DB_DSCR packet field definitions, the parameters that are shown in the following table

are displayed in the trace message.

• I. Init

• M. More

• MS. Master/Slave

Parameter Definition

TX/RX TX refers to a packet transmitted by the device. RX refers to packets received by the

device.

Intf The interface that the packet came in or went out on. Format used is slot/port (internal

interface number).

SrcIp The source IP address in the IP header of the packet.

DestIp The destination IP address in the IP header of the packet.

AreaId The area ID in the OSPF header of the packet.

Type Could be one of the following:

Parameter Definition

Netmask The netmask in the hello packet.

DesignRouter Designated Router IP address.

Backup Backup router IP address.

Field Definition

MTU MTU

Options Options in the OSPF packet.

Flags Could be one or more of the following:

Seq Sequence Number of the DD packet.
